Features
10-inch touch color screen display
10-inch touch color screen display, easy to operate, save space, safe and reliable operation, simple and friendly interface, with complete operation prompts, concise and clear
Narrow panel Auxiliary Feeder
Small panel auxiliary feeding device, can seal the narrow side
Minimum size:
40*300mm (when sealing the long side)
45*200mm (when sealing the narrow side)
Large panel auxiliary wheel + narrow side support wheel
Multiple sets of auxiliary wheels can avoid too much shaking when sealing large or long boards
Narrow edge support wheels make the edge banding more accurate and the end edge banding is more stable
Automatic Oil Filling System
According to the use time of the equipment and the frequency of edge banding, the guide rail chain is automatically lubricated to ensure long-term operation stability and smooth processing, and prolong the service life of the machine
Double glue pot and Quick hot melt Device with automatic glue suction device
From the picture, you can see that there are two glue pots, one PUR glue pot (upper glue pot), one EVA glue pot (lower glue pot), and Quick hot melt Device with automatic glue suction device
The advantage of the double glue pot is that according to different colors of panels and different colors of edge banding, you can choose different colors of glue to solve the problem of glue lines
Quick hot melt Device with automatic glue suction device， It only takes 15 minutes to start working at the fastest, and there is no need to wait for the glue to melt during mass production. Avoid the trouble of manual gluing, work uninterruptedly, and avoid dry burning of the glue pot. automatic glue suction device , no need work add the glue all the time with big Glue storage tank
Bake Light
Bake Light -preheating, avoid degumming
After the baking lamp preheats the edge of the board, the glue is applied to seal the edge more tightly, and the edge band is pasted more firmly, which can avoid the problem of degumming caused by large temperature differences
Double Fine Trimming
The edge is trimmed by the double fine trimming device, which meets the automatic switching of two edge banding belts, saving time and effort, and more effectively improving the edge banding effect
Corner Rounding Unit
Corner rounding unit for soft and postforming workpieces for the processing of the ends of the panel with 0.4-3.0 mm edge material
and 10-60 mm workpiece height, With 2pcs 0.37kw motors. Suitable for straight workpiece edges.
Independent lifting of the pressure beam
The pressing unit, aligning unit and tracking unit all use independent lifting to prevent the panel from shaking and shifting, making it tighter and more stable, with precise edge banding
