Features
Control system
Taiwan Syntec control system
User-friendly interface, easy operation and fast response.
After-sales service points all over the world
High speed spindle router 2 pcs 6kw and 9V drilling unit
Powerful 6kw air cooling Spindle, 18000rpm,
Powerful twisting force and fast processing,
is suitable for heavy cutting, milling etc.,
will keep the surface of work pieces very smooth
Precision Drill Unit
HUAHUA CNC precision drilling unit manufactured in accordance with international standards, high precision.
Taiwan Syntec servo motor and driver and importd reducer
Professionally made, ensure the machine
running accurately in safe with very good
resolution and accuracy.
High Precision Ball screw transmission
The transmission error of the screw rod is within 0.05-0.1MM, and the cumulative error is within 0.1MM, which improves the precision of the whole machine.
Imported linear guiderail and rack
Precision ground 30 mm imported linear
guide rails attached to the gantry, with centralized
lubrication system to the bearing blocks to
guarantee smooth travel of the spindle motor assembly.
Vacuum Worktable
Material: 2.8CM thickness PVC board; 2.Worktable is divided into 7 parts, 6 big holes in each part to ensure the adsorption is equal.Each area can work independently.
Dry Vacuum pump 7.5kw
vacuum pumps ensure the powerful suction.
Type: Dry
Power: 7.5kw
Suction flowrate:250m3/h per set
Position Pins
It can automatic measure tool length of Z axis
