Features
Main Steel Frame
After the welding of the frame is completed, it is placed for one month, and then heat treated;
Eliminate the residual stress generated during the machining process;
Change the crystal structure inside the material;
Enhance the stability of the subject;
Afterwards, it will be treated for 6 months;
Then send to the machining center for precision machining.
Automatic positioning of pressure beam
Automatically adjust the lifting height of the saw blade and pressure beam according to the thickness of the plate, eliminating the need for manual adjustment, ensuring the stability of the pressure beam and greatly improving equipment safety.
Large and small saws can be lifted independently
According to the thickness of the board, the sawing stroke is automatically positioned to reduce idle time, and the saw base speed reaches 120m/min.
Countertop upgrade design
The table is narrower, effectively preventing edge bursting; the 25mm thickened table is durable and does not deform; the 1.8m*3 air-floating table, with roller-assisted cutting, does not damage the surface of the workpiece.
Lift table automatic loading
The lifting platform automatically loads materials, infrared rays locate the height of the upper plate, and automatically lifts to the corresponding height to improve efficiency and quality.
Magnetic scale positioning
2 positioning scrapers, magnetic scale to set the plate thickness according to the program, quick clamping.
System optimization typesetting
22-inch large screen, the system can be connected with the order disassembly software, and has strong compatibility; PLC programming, comes with optimized layout, saving materials and reducing waste.
Rubberized two-finger structure
The two fingers are wrapped with glue to ensure stable feeding without damaging the workpiece. The speed can reach 85m/min. The glue-wrapped fingers prevent scratches on the surface of the board.
Double pusher device
Double pusher device, which sends the plate to be sawed to the pressing device through the rear feeding device and the front feeding device.
Double pusher combined processing
The double pusher device and clamping hand move independently, and panels of different sizes can be merged together and cut at the same time, saving processing time.
Double pusher large and small plate processing
The double pusher device and clamping hand move independently, and large and small panels can be merged together and cut at the same time, saving processing time.
High precision gear rack
It adopts 6-level grinding and rack-and-pinion transmission, which is precise and stable, has excellent wear resistance, and can maintain long-term stable transportation.
Automatic oil filling system
Automatic timing and quantitative oil injection lubrication ensures long-term operational stability and smooth processing, and extends the service life of the machine.
